TST Startup FU3E
FEIG ELECTRONIC GmbH Page 19 of 29 FU3E_Inbetriebnahme_7_GB.doc
11 Functions
P.
[unit]
Range
Door Functions
Default
000
[Cycles] Door cycle counter display
Display: 1234567 ⇒ 1234. À-key .567
Display: 67 ⇒ 67
005
[Cycles] Displays number of door cycles until maintenance is required.
Display: 1234567 ⇒ 1234. À-key .567
Display: 67 ⇒ 67
010
[s]
0..200
Open hold time 1 (End position Upper - Eo)
0: Automatic closing deactivated
10
011
[s]
0..200
Open hold time 2 (Intermediate hold position - E1)
0 = turned off
10
025
[s]
0..20
Pre-warning time before close
0 = Pre-warning time turned off
0
P.
[unit]
Range
Motor rated data
Default
100
[Hz]
30..200
Motor rated frequency (see nameplate, note Y/∆)
-1
101
[A]
0..9.9
Motor rated current (see nameplate, note Y/∆)
-1
102
[%]
40..100
Power factor cos ϕ (see nameplate: cos ϕ : 0.63 → 63)
-1
103
[V]
100..
500
Motor rated voltage (see nameplate, note Y/∆)
The motor characteristic curve is automatically calculated based on the
rated frequency and nominal voltage.
ATTENTION: 230V drives have 1.7x the rated power when supplied
with 400 V! The maximum data published by the motor and drive
manufacturers must be observed!
-1
130
0..1 Motor rotational field
0 = Right rotating
1 = Left rotating
1
P.
[Unit]
Range
Boost
Default
140
[%]
0..30
Voltage increase of the U/f characteristic curve (Boost) in % of rated
voltage for opening
→ Boost in the lower speed range
0
145
[%]
0..30
Voltage increase of the U/f characteristic curve (Boost) in % of rated
voltage for closing
→ Boost in the lower speed range
0
P.
[Unit]
Range
Selecting the limit switch system
Default
205
0..8 Selecting the positioning system:
0. Limit switch 1 (limit switch as normally closed, pre-limit switch normally
open)
1. Limit switch 2 (limit switch and pre-limit switch normally closed)
2. Incremental encoder (reference switch in lower end position)
3. Absolute encoder DES-A
4. Absolute encoder TST PB-A
5. SSI encoder (only with UL-Version)
6. Reserved
7. Absolute encoder DES-B
8. Absolute encoder TST PD
-1
