Teaching the end positions with electronic limit switches
Default
210
0..5 Selecting the position calibrated by a deadman move ("teach in"):
0: None/Cancel
1: Lower and Upper limit switch (intermediate stop: see P244)
2: Upper limit switch (intermediate stop: see P244)
3: Upper and Lower limit switch
4: Intermediate stop limit switch (P244 is ignored)
5: (all) Lower, Upper and Intermediate Stop limit switch (per P244)
0
P.
[Unit]
Range
Correcting end positions with electronic limit switches
Default
215
0..1 Request a new calculation of the pre-end switch positions and limit switch
bands
0: Do not correct
1: Request correction of limit switch bands and pre-limit switches
Parameter only active if automatic correction
Default is set.
0
221
[Inc]
± 125
Correction value for Lower end position
(set to 0 after new calibration !)
0
231
[Inc]
± 60
Correction value for Upper end position
(set to 0 after new calibration !)
0
P.
[Unit]
Range
Reference switch profile
Default
25F
0..9 0: The lower end position must be positioned at in deadman mode and
saved.
1: After power-up the system automatically synchronizes to a Lower
reference switch.
2: After power-up the system automatically synchronizes to the safety
edge.
3: After power-up the system automatically synchronizes to an Upper
reference switch.
4: After power-up the system automatically synchronizes to an Upper
mechanical stop.
5: After power-up the system automatically synchronizes to the safety
edge and then to an Upper mechanical stop.
6: After power-up the system automatically synchronizes to the safety
edge and then to an Upper reference switch.
7: After power-up the system automatically synchronizes to an upper
reference switch and then to the Upper mechanical stop.
8: Synchronization to mechanical stop in Door OPEN and CLOSE
position
9: Manually synchronisation to Door OPEN and CLOSE position
-1
P.
[Unit]
Range
Speeds
Default
310
[Hz]
6..200
Frequency for fast open
(travel frequency until Upper pre-limit switch) → adjust pre-limit switch as
necessary
60
350
[Hz]
6..200
Frequency for fast close
(travel frequency until Lower pre-limit switch) → adjust pre-limit switch as
necessary
ATTENTION: Note closing forces on safety edge!
40
