4.1 Version without housing
Observe technical data and required clearances
The board set is mounted on a mounting frame and can be installed in another housing together with the
attached expansion cards. To do this, consider the space required between the board set and the housing
wall.
The following accessories are included with the board variants:
• Two safety clips for transport security in the housing
• Two sliders as quick release fasteners for the mounting adapter
• An EMC bracket as spacer and grounding of the motor shield in steel / stainless steel housings
Depending on the installation, additional spacers are required. These are not included in the scope of
delivery!
