TST
Assembly instructions
FUZ2 -A/-B/-C/-CX/-G/-L
FEIG ELECTRONIC GmbH
Page 17 of 96
TST_FUZ2-A-B-C-CX-G-L_Montageanleitung_EN_22.docx
4.1.1 Dimensions of the drillings in the mounting frame
Table 1: Drill hole dimensions of the mounting frame
Pos.
Measurement
Description
a
185.6 mm
Total width
b
36.0 mm
Height mounting hole bottom
c
181.2 mm
Height mounting hole top
d
255.5 mm
Total height
Figure 1: Mounting holes in mounting frame without quick-release fastener
a
b
c
d
