Feig Electronic TST FUZ2-C User Manual

FUZ2 -A/-B/-C/-CX/-G/-L
Assembly instructions
TST
FEIG ELECTRONIC GmbH
Page 42 of 96
TST_FUZ2-A-B-C-CX-G-L_Montageanleitung_EN_22.docx
6.5.2 Electrical resistance safety edge
8K2
Outside
white
Inside
brown
66
65
64
63
62
61
brown
white
Jumper J 801 is located to
the left and behind
terminal 51 - 52
J801 = 1-2
8,2K
1,2K
4
digital
Parameter P.5A2 = 3
3
2
1
Figure 21: Connection of an electrical resistance safety edge
6.5.3 Digital input
66
65
64
63
62
61
Jumper J 801 is located to
the left and behind
terminal 51 - 52
J801 = 3-4
8,2K
1,2K
4
digital
Parameter P.5A2 = 0
3
2
1
Figure 22: Connection of an electrical resistance safety edge
