TST
Assembly instructions
FUZ2 -A/-B/-C/-CX/-G/-L
FEIG ELECTRONIC GmbH
Page 25 of 96
TST_FUZ2-A-B-C-CX-G-
L_Montageanleitung_EN_22.docx
5.3 Housing variant 2 / large housing
This type of housing is used for controller types TST FUZ2-CGH, TST FUZ2-B, and -LGH.
Figure 9: Installation in large housing
415
179
Floor
Ca. 1300
89,5
Figure 10: Drilling template large housing
Min. 100mm
Min. 100mm
