Page #92 background imageLoading...
Page #92 background image
FUZ2 -A/-B/-C/-CX/-G/-L
Assembly instructions
TST
FEIG ELECTRONIC GmbH
Page 92 of 96
TST_FUZ2-A-B-C-CX-G-L_Montageanleitung_EN_22.docx
General inputs
E.000
OPEN key on membrane keypad
E.050
STOP key on membrane keypad
E.090
CLOSE key on membrane keypad
E.101
Input 1
E.102
Input 2
E.103
Input 3
E.104
Input 4
E.105
Input 5
E.106
Input 6
E.107
Input 7
E.108
Input 8
E.109
Input 9
E.110
Input 10
E.111
Input 11
E.112
Input 12
E.113
Input 13
E.114
Input 14
E.115
Input 15
E.121
Input 21
E.122
Input 22
E.123
Input 23
E.124
Input 24
E.125
Input 25
E.126
Input 26
E.127
Input 27
E.128
Input 28
E.13A
Input 3A
E.13B
Input 3B
E.13C
Input 3C
E.13D
Input 3D
E.13E
Input 3E
E.13F
Input 3F
Safety- / emergency stop chain
E.201
Internal emergency STOP “mushroom buttom” triggered
E.211
External emergency stop 1 triggered
E.212
External emergency stop 2 triggered
Safety edge in general
E.360
E.380: Triggering of the 2nd internal safety edge
E.363
Internal safety edge 1 faulty
E.370
Triggering of the 2nd external safety edge
E.373
External safety edge fault
E.379
External safety edge activated but not yet plugged in
E.380
Triggering of the 2nd internal safety edge
E.383
Interruption of the 2nd internal safety edge
E.3F0
Triggering of the 2nd external safety edge
E.3F3
Interruption of the 2nd internal safety edge
Wireless plug-in module
E.401
Wireless Channel 1
E.402
Wireless Channel 2
Inductive loop
E.501
Detector channel 1
E.502
Detector channel 2
E.503
Detector channel 3
E.504
Detector channel 4
Internal-Inputs
E.900
Controller chip fault signal
