Felder A 941 - Electrical and Mechanical Data; Electrical Connection and Drive Motor

16
Planer-Thicknesser
A 941 / AD 941 / AD 951
Machine A 941 / AD 941 AD 951
Cutterblock diameter (knife flight)-Ø 88 mm 119 mm
Number of knives *) 2 / 3 / 4 / Silent Power 4 / Silent Power
Speed 50/60 Hz 4700 min-1 4700 min-1
*) depending on the equipment
Machine AD 941 AD 951
Thicknesser table length 620 mm 900 mm
Thicknessing width 404 mm 504 mm
Thicknessing height Min./Max. 3 / 250 mm 3 / 254 mm
Feed rate (AD 951: infinitely variable) 6 + 12 m/min 4–16 m/min
Depth of cut Max. 5 mm 5 mm
Machine A 941 / AD 941 AD 951
Planer table length 1080 mm 1095 mm
Total planer table length 2200 mm 2252 mm
Surface planing width 410 mm 510 mm
Planer fence - tiltable from 90° to 45° 90° to 45°
Fence guide 170 x 1300 mm 170 x 1300 mm
Depth of cut Max. 5 mm 5 mm
Alternating-current motor Three-phase current motor
Motor voltage 1x 230 V 3x 230 V / 3x 400 V
Motor frequency 50/60 Hz 50/60 Hz
System of protection IP 55 IP 55
Motor power S6-40 %
*
)
Standard 3 kW 4 kW
Option - - - 5,5 kW, 7,35 kW
Option AD 951 - - - 10 kW
Geared motor AD 951 0,55 kW
*) S6 = operation under load and intermittent service; 40% = relative operating factor
4.6 Planer unit
4.3 Electrical connection/Drive motor
4.4 Cutterblock
4.5 Thicknesser unit
The actual values can be found on the data plate.
Technical data
