25
W
W + 500 mm
!
Planer-Thicknesser
A 941 / AD 941 / AD 951
Note: Ensure that there is sufficient space to work around the machine.
In order to maintain and operate the machine properly, it must be set up at least 500 mm away from the
wall,
parallel to the work direction (measurement X).
To operate and maintain the machine, leave a min. of 2000 mm space all around the machine.
Fig. 6-4: Space requirements
Transport, packaging and storage
Installation site requirements:
• Operation/room temperature: +10° to +40° C
• Ensure that the work surface is sufficiently stable and
has the proper load-bearing capacity
• Provide sufficient light at the workstation
• Ensure there is sufficient clearance for or from
neighbouring workstations
When installing the machine, ensure that there is suffici-
ent space for the machine operator, including the space
required to move workpieces (loading, processing, sta-
cking).
6.7 Floor space requirement
Attention! Risk of material damage!
The machine may only be used in a dry and frost-free environment and may not be used outside.
