Planer-Thicknesser
A 941 / AD 941 / AD 951
!Data plate
"Motor protection switch button
#Danger! Electric current!
$Control panel covers (with options)
depending on the equipment - See chapter entitled:
>Operation and display elements<
%Scale - Bridge guard
&Scale - Planer fence
/Adjusting the planer fence
*Under table rollers (Option)
)Gear lever (AD 941)
BLChangeover position
Fig. 12-1: machine base-frame
12.1 Overview - pictograms, signs and labels
Note: All the pictograms, signs and labels affixed to the machine must be kept visible, readable and may not
be removed.
