45
Planer-Thicknesser
A 941 / AD 941 / AD 951
Operation
9.4.6 Beveling/chamfering
Fig. 9-7.1: Protective rail
Fig. 9-7.2: Jig
1. Take note of general procedures for authorized
working techniques.
2. Adjust guard rail (see Fig.)
3. Set the planer fence to any angle and continue as
described in the »Jointing« section.
Tapering/beveling small workpieces
You must always use a special jig for beveling small,
narrow workpieces.
This device can also be used to bevel long workpieces.
Attach the jig to the planer fence.
Set the planer bridge guard all the way down and let the
bridge guard contact the jig.
Note: To prevent the workpiece from slipping from the angled surface, press the workpiece mainly against the
fence and only lightly against the planer tables.
