INSTALLING THE BUILT-IN MONITOR
197mm
131mm
F1 F2
MENU
14mm
XXmm
1
Monitor Dimensions (Height x Width x Depth*.):
197 x 131 x 60 mm / 7,7” x 5,1” x 2,3”
Pure model Monitor Dimensions (Height x Width x Depth*.):
197 x 131 x 59 mm / 7,7” x 5,1” x 2,3”
Fermax Box Dimensions (Height x Width x Depth):
158 x 108 x 45 mm / 6,2” x 4,2” x 1,7”
Universal Box Dimensions (Height x Width x Depth):
174 x 114 x 50 mm / 6,8” x 4,5” x 2”
Notes:
- this monitor can be installed in a universal box.
- Depth* : the Monitor depth stated here takes into account
the Fermax box
1
.6
0
m
5
.2
5
fe
e
t
(*)
(*)
1.60m
5.25 feet
(*)
(*)
Installation with a FERMAX BOX
Installation with UNIVERSAL BOX
2b
3
3
1.60m
5.25 feet
Ct
+MV
MV
F1
T
A+ L-
F2
2a
1.60m
5.25 feet
Ct +MV
MVF1
T
A+ L-
F2
(*) Remove the electrostatic protective tag .
(*) Remove the electrostatic protective tag.
