12
EN
Cod. 3540001190 - Rev. 00 - 11/2023
HYDRAULIC ELECTRONIC BOARD BOX
4. INSTALLATION
4.1 Dimension
330mm
65mm
fig. 2 -
4.2 Kit installation
Drill four holes where you want to install the kit, with the positions of the holes shown below. Secure the kit using screws.The kit must be installed vertically on the wall.
Wall or obstacle Wall or obstacle
≥600mm≥300mm≥300mm
fig. 3 -
From the front From the side
NOTE
All pictures in this manual are for reference only. The actual product may be slightly different from the above pictures.
