5. Maintenance and conversion
5−36
Festo P.BE−MPA−EN en 0910d
MPA−S valve terminal with CPX terminal
Note
Maximum 16 MPA sub−bases are permitted on the MPA−S
valve terminal with CPX terminal and electric supply plate.
Without the electric supply plate 8 MPA sub−bases are
permitted.
Necessary components
For extension you will require:
Components
MPA−S valve terminal with ...
CPX terminal Multi−pin plug
connection
One sub−base per:
 MPA1: 4 valve positions
 MPA2: 2 valve positions
VMPA1−FB−AP−4−1
1)
or VMPA1−FB−AP−4−1−...
2)
VMPA2−FB−AP−2−2
1)
or VMPA2−FB−AP−2−2−...
2)
One electronics module per sub−base see Tab.5/3 see Tab.5/4
Valve or blanking plates:
 MPA1: 4 per sub−base
 MPA2: 2 per sub−base
VMPA...−M1H−...
VMPA...−M1H−...
If necessary, additional pneumatic supply plate:
 with exhaust plate
 with flat plate silencer
VMPA...−FB−SP
VMPA...−FB−SPU
If necessary, additional electric supply plate:
 With plug M18
 With plug 7/8" (4−pin)
 With plug 7/8" (5−pin)
VMPA−FB−SP−V
VMPA−FB−SP−7/8−V−4POL
VMPA−FB−SP−7/8−V−5POL
−−−−
For every added sub−base or pneumaticsupply
plate, the appropriate interlinking boards:
 Interlinking board for sub−base
 Interlinking boards for pneumatic supply plate
VMPA1−FB−EV−AB
VMPA1−FB−EV−V
see Tab.5/5
