1. Summary of components
1−7
Festo P.BE−MPA−EN en 0910d
MPA−S valve terminal with
multi−pin plug connection
This variant of the MPA−S valve terminal is available in the
following grades:
MPA−S valve terminal with ...
Number of valve positions
... Multi−pin plug connection
1)
MPA1
4, 8, 12 ... 24
MPA2
2, 4, 6, ... 24
1)
A maximum of 24 solenoid coils can be actuated. The electrical connection of the solenoid
coils is made centrally via the multi−pin plug connector.
Tab.1/3: Number of valve locations on the MPA−S valve terminal with multi−pin plug
connection
Fig.1/3: MPA−S valve terminal with multi−pin plug
connection
MPA−S valve terminal with
AS interface
This variant of the MPA−S valve terminal is available in the
following grades:
