Pressure regulator plates
The pressure regulator plates of the vertical stacking are
marked on the MPA−S valve terminal with the ident. code.
Thisis marked on the side of the pressure regulator plate.
You can identify the pressure regulator plate using the
following table.
ID
code
Vertical stacking components
PF P pressure regulator plate for port (1), control range 0.5 ... 6 bar
PH P pressure regulator plate for port (2), control range 2 ... 6 bar
PG A pressure regulator plate for port (4), control range 2 ... 6 bar
PN Reversible B pressure regulator plate for port (2), control range 0.5 ... 6 bar
PM Reversible A pressure regulator plate for port (4), control range 0.5 ... 6 bar
PA P pressure regulator plate for port (1), control range 0.5 ... 10 bar
PC B pressure regulator plate for port (2), control range 2 ... 10 bar
PB A pressure regulator plate for port (4), control range 2 ... 10 bar
PM Reversible B pressure regulator plate for port (2), control range 0.5 ... 10 bar
PK Reversible A pressure regulator plate for port (4), control range 0.5 ... 10 bar
T Pressure gauge for pressure regulator plate
Tab.1/10: Identification of the pressure regulator plates in the type code
The circuit symbol of the pressure regulating valve is
provided in appendix B, Tab.B/5.
