IN CASE OF EMERGENCY
150
required by the regulations in force). In
any case, follow the road safety laws
in force in the country where you are
driving;
insert the sealant cartridge (A)
into the corresponding compressor
compartment (B)and press it down
hard fig. 187. Remove the speed limit
sticker (C) and apply it in a clearly
visible position fig. 188;
188 F0T0932
wear the gloves;
remove the cap from the tyre valve
and connect and screw the transparent
tube of the sealant (D) fig. 187 onto the
valve. If a 250 ml cartridge is present
the housing of the transparent tube
is provided with removable ring to
facilitate extraction. Make sure that the
ON/OFF button (E) fig. 189 is in the off
position (button not pressed);
189 F0T0933
plug the electrical connector (F)
fig. 190 into the 12V socket of the
vehicle and start the vehicle engine;
190 F0T0934
operate the compressor by pressing
the ON/OFF button (E) fig. 189.
When the pressure shown in Owner
Handbook or on the specific label
appears on the pressure gauge (G),
stop the compressor by pressing the
ON/OFF button (E) again;
disconnect the cartridge (A) from the
compressor, by pressing the release
button (H) and lifting the cartridge (A)
upwards fig. 191.
191 F0T0935
If the pressure gauge (G) fig. 189
indicates a pressure lower than
1.8 bar / 26 psi 15 minutes after
starting the compressor, switch off the
compressor, disconnect the sealant
tube (D) from the tyre valve and remove
the cartridge (A) from the compressor
fig. 191.
Move the vehicle by approximately
10 m to promote the distribution of
sealant; stop the vehicle safely, operate
the handbrake and restore pressure
using the black inflation pipe (L) fig. 192
to reach the required pressure. If also
in this case, the pressure is lower
than 1.8 bar / 26 psi 15 minutes after
turning on, do not resume driving but
contact a Fiat Dealership.
