KNOWING YOUR VEHICLE
42
immediately when one of the doors is
opened.
23)
MANUAL FRONT
WINDOWS
On some versions, the front windows
are opened and closed manually.
Wind the handle to open/close.
WARNING
23)
Improper use of the electric windows
can be dangerous. Before and during
operation, always check that nobody is
exposed to the risk of being injured either
directly by the moving window or through
objects getting caught or hit by it. When
leaving the vehicle, always remove the key
from the ignition switch to avoid the risk of
injury to anyone remaining in the vehicle
due to accidental operation of the electric
windows.
BONNET
OPENING
Proceed as follows:
55 F0T0045
pull the lever (A) fig. 55 in the
direction indicated by the arrow;
operate the lever (B) fig. 56 and lift
the bonnet;
56 F0T0067
lift the bonnet;
lift the engine bonnet (A) fig. 57
supporting lever it until it clicks;
57 F0T0216
24)
CLOSING
Proceed as follows:
58 F0T0283
lift the bonnet with one hand and
pull the device (A) fig. 58 yourself while
lowering the lever (B);
lower the bonnet to approximately
20 centimetres from the engine
compartment and let it drop. Make
sure that the bonnet is completely
closed and not only fastened by the
locking device by trying to open it. If it
