Fiat FIORINO 2021 - Heating and Ventilation

37
CENTRAL AND SIDE
VENTS
48 F0T0031
(A) Adjustable side vent fig. 48
(B) Fixed vent for side windows fig. 48
(C) Adjustable central vents fig. 49
49 F0T0030
To use the vents (A) e (C), adjust them
as required.
HEATING AND
VENTILATION
CONTROLS
50 F0T0074
The main heating and ventilation
commands are listed below fig. 50:
A air temperature adjustment knob
(hot/cold air mixing)
B internal air recirculation on/off slider
C fan activation knob
D air distribution knob.
CLIMATIC COMFORT
Knob (D) allows the air introduced into
the vehicle to reach all parts of the
passenger compartment through five
distribution options:
delivers air from central and side
vents;
warms the feet and keeps the
face cool (bi-level function)
warms up the passenger
compartment faster;
warms up the passenger
compartment and demists the
windscreen at the same time;
demists and defrosts the
windscreen and front side
windows.
HEATING
Proceed as follows:
turn knob (A) all to the right (to );
turn knob (C) to the required speed.
turn knob (D) to:
to warm the feet and demist the
windscreen at the same time;
to send air to the feet and
introduce fresher air from the central
and dashboard vents;
to warm up quickly.
FAST HEATING
Proceed as follows:
close all the vents in the dashboard
turn the knob (A) to ;
turn the knob (C) to 4 ;
turn the knob (D) to .
RAPID WINDSCREEN
AND FRONT
SIDE WINDOWS
DEMISTING/DEFROSTING
(MAX-DEF function)
Proceed as follows:
