149
it only in the positions indicated. Do not
use the jack for loads higher than the one
shown on its label. Never start the engine
with vehicle raised. If the vehicle is raised
more than necessary, everything can
become more unstable, with the risk of the
vehicle dropping violently. Thus, lift the
vehicle only as needed in order to access
the spare wheel.
126)
Incorrect hub cap assembly may
cause it to come off when the vehicle is
moving. Never tamper with the inflation
valve. Never introduce tools of any kind
between rim and tyre. Check tyre and
space-saver wheel pressures regularly,
complying with the values given in the
"Technical specifications" chapter.
127)
Never use the space-saver spare
wheel for more than strictly necessary and
never exceed 80 km/h. On the space-
saver wheel there is an orange label,
summarising the main warnings regarding
usage restrictions. Never remove or cover
the label. Warning! For temporary use only!
80 km/h max.! Replace by standard wheel
as soon as possible.
IMPORTANT
27)
When turning the jack handle make
sure that it can turn freely without scraping
your hand against the ground. The moving
components of the jack ("worm screw"
and joints) can also cause injuries: avoid
touching them. If you come into contact
with lubricating grease, clean yourself
thoroughly.
28)
Contact a Fiat Dealership as soon as
possible to have the correct tightening of
the fixing bolts checked.
FIX & GO
AUTOMATIC KIT
128) 129)
29)
The Fix&Go automatic quick tyre repair
kit is located in a special container in
the boot.
The Fix&Go Automatic kit is located
in the luggage compartment on the
left rear wheel arch (A) fig. 186 (Fiorino
Combi and Qubo versions).
On Fiorino Cargo versions, the Fix&Go
repair kit is located behind the driver's
seat.
186 F0T0355
The quick tyre repair kit contains
fig. 187:
one cartridge (A) containing sealant
and fitted with: transparent tube for
injecting the sealant (D) and sticker (C)
with the wording "Max. 80 km/h" to be
placed in a clearly visible position (e.g.
on the dashboard) after repairing the
tyre;
one compressor (B);
a pair of gloves located in the hose
compartment of the cartridge (D).
187 F0T0931
TYRE REPAIRING AND
PRESSURE RESTORING
PROCEDURE
Proceed as follows:
stop the vehicle in a position that
is not dangerous for oncoming traffic
where you can carry out the procedure
safely. The ground must be flat and
sufficiently compact;
stop the engine, engage the hazard
warning lights and the parking brake;
before getting out of the vehicle,
put on the reflective safety jacket (if
