187
AIR CLEANER/
POLLEN FILTER
Have the air cleaner or the pollen filter
replaced by a Fiat Dealership.
WINDSCREEN
WIPER/REAR
WINDOW WIPER
(for versions/markets, where provided)
WIPER BLADES
Periodically clean the rubber part
using special products; PETRONAS
DURANCE SC 35 is recommended.
Replace the blades if the rubber
edge is deformed or worn. In any
case, it is advisable to replace them
approximately once a year.
A few simple precautions can reduce
the possibility of damage to the blades:
if the temperature falls below zero,
make sure that ice has not frozen the
rubber to the glass. Use a de-icing
product to release it if required;
remove any snow from the glass:
in addition to protecting the blades,
this prevents effort on the motor and
overheating;
do not operate the windscreen and
rear window wipers on dry glass.
160)
Replacing the
windscreen wiper
blades
Proceed as follows:
lift up the windscreen wiper arm and
position the blade so that it forms a 90°
angle with the arm;
press tabs (A) fig. 239 and remove
the blade from the arm;
install the new blade by inserting the
straps into the supplied housings of the
arm. Make sure that the new blade is
secured in position.
239 F0T0087
Replacing the rear
window wiper blade
(for versions/markets, where provided)
Proceed as follows:
raise the cover (A) fig. 240 (Fiorino
versions) or fig. 240 (Qubo versions)
and remove the arm from the vehicle,
undoing the nut (B) which fixes it to the
pivot pin;
correctly position the new arm and
tighten the nut fully;
lower the cover.
240 F0T0088
241 F0T0213
NOZZLES
If the jet is not coming out, firstly check
that there is fluid in the windscreen/rear
window reservoir (for versions/markets
where provided) (see “Checking levels”
in this section).
Then check that the nozzle holes are
not clogged; use a needle to unblock
them if necessary.
