39
The additional heater turns off
automatically after the required comfort
conditions are achieved.
WARNING The heater will not turn on if
the battery voltage is too low.
MANUAL CLIMATE
CONTROL SYSTEM
(for versions/markets, where provided)
CONTROLS
52 F0T0029
The main heating and ventilation
commands are listed below fig. 52:
A air temperature adjustment knob
(hot/cold air mixing);
B internal air recirculation on/off slider;
C fan and climate control system on/off
knob;
D air distribution knob.
CLIMATIC COMFORT
Knob (D) allows the air introduced into
the vehicle to reach all parts of the
passenger compartment through five
distribution options:
delivers air from central and side
vents;
warms the feet and keeps the
face cool (bi-level function)
warms up the passenger
compartment faster;
warms up the passenger
compartment and demists the
windscreen at the same time;
demists and defrosts the
windscreen and front side
windows.
HEATING
Proceed as follows:
turn knob (A) all to the right (to );
turn knob (C) to the required speed.
turn knob (D) to:
to warm the feet and demist the
windscreen at the same time;
to send air to the feet and
introduce fresher air from the central
and dashboard vents;
to warm up quickly.
FAST HEATING
Proceed as follows:
close all the vents in the dashboard
turn the knob (A) to ;
turn the knob (C) to 4 ;
turn the knob (D) to .
RAPID WINDSCREEN
AND FRONT
SIDE WINDOWS
DEMISTING/DEFROSTING
(MAX-DEF function)
Proceed as follows:
turn the knob (A) to ;
turn the knob (C) to 4 ;
turn the knob (D) to ;
bring cursor to (B) to .
After demisting/defrosting, operate
the controls as normal to restore the
required comfort conditions.
WARNING The climate control system
is very useful for faster demisting
because it dries the air. Adjust the
controls as described above and
engage the climate control by pressing
knob (C).
Window demisting
In the event of considerable external
moisture and/or rain and/or large
differences in temperature inside and
outside the passenger compartment,
