207
WHEELS
RIMS AND WHEELS
Pressed steel or alloy rims. Tubeless
radial carcass tires. All approved tyres
are listed in the registration document.
WARNING If there are any
discrepancies between the Owner
Handbook and the registration
document, take the information from
the latter. To ensure driving safety,
ensure that tyres of the same make
and type are fitted on all wheels.
WARNING Do not use air chambers
with tubeless tyres.
SPARE WHEEL
170)
Pressed steel rim.
Tubeless tyre.
WHEEL GEOMETRY
Front wheels toe-in measured between
rims: -1 ± 1 mm.
The values refer to the vehicle in
running order.
CORRECT READING OF
THE TYRE
Example: 185/65 R 15 88T (see
fig. 253)
253 F0T0014
185 Nominal width (S, distance in mm
between sides)
65 Height/width ratio (H/S), expressed
as a percentage
R Radial tyre
15 Rim diameter in inches (Ø)
88 Load rating (capacity)
T Maximum speed rating
Maximum speed index
Q up to 160 km/h
R up to 170 km/h
S up to 180 km/h
T up to 190 km/h
U up to 200 km/h
H up to 210 km/h
V up to 240 km/h
W up to 270 km/h
Y up to 300 km/h
Maximum speed index for snow
tyres
QM + S up to 160 km/h
TM + S up to 190 km/h
HM + S up to 210 km/h
Load index (capacity)
Load index (capacity)
60 = 250 kg 84 = 500 kg
61 = 257kg 85 = 515 kg
62 = 265 kg 86 = 530 kg
63 = 272kg 87 = 545 kg
64 = 280 kg 88 = 560 kg
65 = 290 kg 89 = 580 kg
66 = 300 kg 90 = 600 kg
67 = 307 kg 91 = 615 kg
68 = 315 kg 92 = 630 kg
69 = 325 kg 93 = 650 kg
70 = 335 kg 94 = 670 kg
71 = 345 kg 95 = 690 kg
72 = 355 kg 96 = 710 kg
73 = 365 kg 97 = 730 kg
74 = 375 kg 98 = 750 kg
