TECHNICAL SPECIFICATIONS
208
Load index (capacity)
75 = 387 kg 99 = 775 kg
76 = 400 kg 100 = 800 kg
77 = 412 kg 101 = 825 kg
78 = 425 kg 102 = 850 kg
79 = 437 kg 103 = 875 kg
80 = 450 kg 104 = 900 kg
81 = 462 kg 105 = 925 kg
82 = 475 kg 106 = 950 kg
83 = 487 kg
CORRECT READING OF
THE RIM CODE
Example: 6J x 15 H2 ET 44 (see
fig. 253)
6 width of the rim in inches (1).
J rim drop centre outline (side
projection where the tyre bead rests)
(2).
15 fitting diameter in inches
(corresponds to the diameter of the tyre
to be fitted) ((3) = Ø).
H2shape and number of "humps"
(circumference measurement which
keeps the bead of tubeless tyres in
position on the rim).
ET 44: wheel camber (distance
between the disc/rim supporting plane
and the wheel rim centre line).
RIM PROTECTOR TYRES
254 F0S0351
171)
