29
REAR-VIEW
MIRRORS
INTERIOR MIRROR
(for versions/markets, where provided)
33 F0T0988
The mirror is fitted with a safety device
that causes its release in the event of a
violent impact with the passenger.
Lever (A) fig. 33 can be used to move
the mirror to two different positions:
normal or anti-glare.
DOOR MIRRORS
34 F0T0042
Manual mirror folding
When required (for example when
the mirror causes difficulty in narrow
spaces ) it is possible to fold the mirrors
manually moving them from position (A)
fig. 34 to position (B).
21) 22)
Manual adjustment
From inside, use device (A) fig. 35.
35 F0T0194
Electric adjustment
(for versions/markets, where provided)
Door mirrors can be adjusted only if the
ignition key is in MAR position.
Proceed as follows:
select the desired mirror (left or right)
using switch (A) fig. 36;
36 F0T0041
move switch (A) to position (B) and
operate it to adjust the left door mirror;
move switch (A) to position (D) and
operate it to adjust the right door
mirror.
Once you have finished the adjustment,
return switch (A) to intermediate locking
position (C).
WARNING
21)
While driving the mirrors must remain
in position (A) fig. 34.
22)
As door mirrors are curved, they may
slightly alter the perception of distance.
