159
209 F0T0458
Front ceiling light with map reading
lights
(for versions/markets, where provided)
To replace the bulbs, proceed as
follows:
210 F0T0143
operate in the points shown by the
arrow and remove ceiling light (A)
fig. 210;
open protective flap (B) fig. 211;
replace the bulbs (C) by releasing
them from the side contacts and
making sure that the new bulbs
are correctly secured between the
contacts;
re-close the flap (B) fig. 211 and
fasten the ceiling light (A) fig. 210 in its
housing, making sure that it locks into
place.
211 F0T0144
REAR CEILING LIGHT
Fiorino Cargo versions
To replace the bulb, proceed as
follows:
extract the ceiling light (A) fig. 212 by
operating in the points shown by the
arrows;
open the lid (B) fig. 213 as shown;
212 F0T0107
remove bulb (C) fig. 213 by releasing
it from the side contacts, then insert
the new bulb and make sure it is
correctly clamped between these
contacts;
close the cover (B) fig. 213 and
secure the ceiling light into its housing,
making sure it locks properly into place;
close the cover (B) and secure the
ceiling light into its housing, making
sure it locks properly into place.
213 F0T0458
