33
REAR ROOF LIGHT WITH
MOVABLE LENS
(for versions/markets, where provided)
43 F0T0114
The light comes on automatically when
a front door or sliding side door is
opened and goes out when it is closed.
Press the left-hand side of the lens (A)
fig. 43, as shown in the diagram, to
switch the light on/off when the doors
are closed.
REAR CEILING LIGHT
WITH REMOVABLE
TORCH
(for versions/markets, where provided)
44 F0T0116
The light comes on automatically when
you open the sliding side doors (for
versions/markets where provided) and
the rear swing doors, and goes out
when you close them.
Press switch (A) fig. 44 to turn the light
on/off with the doors closed.
The switch (A) can assume three
different positions:
switch in central position (position 0),
light comes on when a door is opened;
switch pushed up (position 1), light is
always on;
switch pushed down (position 2 -
AUTO OFF), light is always off.
TORCH FUNCTION
(for versions/markets, where provided)
45 F0T0115
This is located on the right side of the
load compartment. It is used as both a
fixed light and a portable electric torch.
To use the removable torch (A) fig. 45 ,
push button (B) and remove the torch
in the direction shown by the arrow.
Then press switch (C) to switch the
light on/off.
When the removable light is secured
to its fixed support, the electric torch
battery is automatically recharged.
With the vehicle stationary and the
ignition key either turned to STOP or
removed, the ceiling light is recharged
for a maximum of 15 minutes.
SWITCHING ROOF
LIGHTS ON/OFF
Cargo versions
The ceiling lights switch on/off in the
following ways:
Ceiling lights on without locking the
doors
Front ceiling light: comes on when the
front doors are opened.
