Fiat FIORINO 2021 - Page 37

35
moving the stalk upwards to the
MIST position, up to three times.
The activations are used to position
the wipers as preferred. The "Service
Position" function is deactivated when
the car is started, with a wiping request
or when the car is moving (speed
above 5 km/h).
WARNING Make sure, when starting
vehicle, that the windscreen is free of
snow or ice before turning the ignition
key.
REAR WINDOW
WIPER/WASHER
(for versions/markets, where provided)
This operates only with the ignition key
turned to MAR.
Activation
Turn the ring nut to to operate the
rear window wiper:
in intermittent mode when the
windscreen wiper is not operating;
in synchronous mode (at half the
speed of the windscreen wiper) when
the windscreen wiper is operating;
in continuous mode with reverse
gear engaged and the control active.
With the windscreen wiper on and
reverse gear engaged, rear window
wiping will be continuous.
Pushing the stalk towards the
dashboard (rocking position) will
activate the rear window washer jet.
Keep the stalk pushed for more than
half a second to activate the rear
window wiper as well. Releasing the
stalk will activate the smart washing
function, as described for the
windscreen wiper.
Deactivation
The function stops when the stalk is
released.
4)
IMPORTANT
3) Never use the screen wiper to remove
layers of snow or ice from the windscreen
glass. In such conditions, the wiper
may be subjected to excessive stress
and the motor cut-out switch, which
prevents operation for a few seconds, may
intervene. If operation is not restored,
contact a Fiat Dealership.
4) Do not use the rear window wiper to
remove layers of snow or ice. In such
conditions, the wiper may be subjected to
excessive stress and the motor cut-out
switch, which prevents operation for a few
seconds, may intervene. If operation is not
restored, contact a Fiat Dealership.
