Fibocom L830-EB User Manual

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved.
L830-EB Hardware User Manual Page 13 of 39
Pin
Pin Name
I/O
Reset
Value
Pin Description
Type
48
TX_BLANKING
O
L
TDMA Timer output, external GPS
control signal.(not supported)
CMOS 1.8V
49
NC
NC
50
NC
NC
51
GND
GND
Power Supply
52
NC
NC
53
NC
NC
54
NC
NC
55
NC
NC
56
NC
NC
57
GND
GND
Power Supply
58
NC
NC
59
ANTCTL0
O
L
Tunable antenna control signal, bit0
(not supported yet).
CMOS 1.8V
60
COEX3
O
Reserved
61
ANTCTL1
O
L
Tunable antenna control signal, MIPI
RFFE SDATA, bit1 (not supported
yet).
CMOS 1.8V
62
COEX2
O
Reserved
63
ANTCTL2
O
L
Tunable antenna control signal, MIPI
RFFE SCLK, bit2 (not supported
yet).
CMOS 1.8V
64
COEX1
O
Reserved
65
ANTCTL3
O
Tunable antenna control signal, MIPI
RFFE VIO, bit3 (not supported yet).
CMOS 1.8V
66
SIM_DETECT
I
SIM card detect, external 390KΩ
pull-up.
CMOS 1.8V
67
RESET#
I
External reset input signal, internal
100KΩ pull-up.
CMOS 1.8V
68
NC
NC
69
CONFIG_1
O
L
Connected to internal GND, L830

Fibocom L830-EB Specifications

General

Category	Computer Hardware
Manufacturer	Fibocom
Model	L830-EB
Form Factor	M.2
Operating Temperature	-10°C to +55°C
LTE Bands	B1/B3/B5/B7/B8/B20
3G Bands	B1/B5/B8
Data Rate	LTE Cat4: 150Mbps DL / 50Mbps UL
Interface	PCIe, USB 2.0
Operating Voltage	3.135V to 4.4V
