L830-EB Hardware User Manual Page 6 of 39
1 Preface
1.1 Introduction
The document describes the electrical characteristics, RF performance, dimensions and application
environment, etc. of L830-EB (hereinafter referred to as L830). With the assistance of the document and
other instructions, the developers can quickly understand the hardware functions of L830 modules and
develop products.
1.2 Reference Standard
The design of the product complies with the following standards:
 3GPP TS 34.121-1 V10.8.0: User Equipment (UE) conformance specification;Radio
transmission and reception (FDD);Part 1: Conformance specification
 3GPP TS 36.521-1 V10.6.0: User Equipment (UE) conformance specification; Radio
transmission and reception; Part 1: Conformance testing
 3GPP TS 21.111 V10.0.0: USIM and IC card requirements
 3GPP TS 51.011 V4.15.0: Specification of the Subscriber Identity Module -Mobile Equipment
(SIM-ME) interface
 3GPP TS 31.102 V10.11.0: Characteristics of the Universal Subscriber Identity Module (USIM)
application
 3GPP TS 31.11 V10.16.0: Universal Subscriber Identity Module (USIM) Application
Toolkit(USAT)
 3GPP TS 36.124 V10.3.0: ElectroMagnetic Compatibility (EMC) requirements for mobile
terminals and ancillary equipment
 3GPP TS 27.007 V10.0.8: AT command set for User Equipment (UE)
 PCI_Express_M.2_Specification_Rev1.1
1.3 Related Documents
 RF Antenna Application Design Specification
 L8-Family System Driver Integration and Application Guidance
 L8-Family AT Commands Manual

Fibocom L830-EB Specifications

General

Category	Computer Hardware
Manufacturer	Fibocom
Model	L830-EB
Form Factor	M.2
Operating Temperature	-10°C to +55°C
LTE Bands	B1/B3/B5/B7/B8/B20
3G Bands	B1/B5/B8
Data Rate	LTE Cat4: 150Mbps DL / 50Mbps UL
Interface	PCIe, USB 2.0
Operating Voltage	3.135V to 4.4V
