Fibocom L830-EB User Manual

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved.
L830-EB Hardware User Manual Page 14 of 39
Pin
Pin Name
I/O
Reset
Value
Pin Description
Type
M.2 module is configured as the
WWAN-SSIC 0 interface type.
70
+3.3V
PI
Module main power input.
Power Supply
71
GND
GND
Power Supply
72
+3.3V
PI
Module main power input.
Power Supply
73
GND
GND
Power Supply
74
+3.3V
PI
Module main power input.
Power Supply
75
CONFIG_2
O
L
Connected to internal GND, L830
M.2 module is configured as the
WWAN-SSIC 0 interface type.
Reset Value: The initial status after module reset, not the status when working
H: High Voltage Level
L: Low Voltage Level
PD: Pull-Down
PU: Pull-Up
T: Tristate
OD: Open Drain
PP: Push-Pull
PI: Power Input
PO: Power Output
Note:
The unused pins can be left floating.
3.2 Power Supply
The power interface of L830 module as shown in the following table:

Fibocom L830-EB Specifications

General

Category	Computer Hardware
Manufacturer	Fibocom
Model	L830-EB
Form Factor	M.2
Operating Temperature	-10°C to +55°C
LTE Bands	B1/B3/B5/B7/B8/B20
3G Bands	B1/B5/B8
Data Rate	LTE Cat4: 150Mbps DL / 50Mbps UL
Interface	PCIe, USB 2.0
Operating Voltage	3.135V to 4.4V
