4.2 Operating Band
The L830 module operating bands of the antennas are as follows:
Operating
Band
Description
Mode
Tx (MHz)
Rx (MHz)
Band 1
IMT 2100MHz
LTE FDD/WCDMA
1920 - 1980
2110 - 2170
Band 3
DCS 1800MHz
LTE FDD
1710 - 1785
1805 - 1880
Band 5
CLR 850MHz
LTE FDD/WCDMA
824 - 849
869 - 894
Band 7
IMT-E 2600Mhz
LTE FDD
2500 - 2570
2620 - 2690
Band 8
E-GSM 900MHz
LTE FDD/WCDMA
880 - 915
925 - 960
Band 20
EUDD 800MHz
LTE FDD
832 - 862
791 - 821
Band 28
APT700
LTE FDD
703-748
758-803
Band 32
L-Band1500
LTE FDD
N/A
1452-1496
4.3 Transmitting Power
The transmitting power for each band of the L830 module as shown in the following table:
Mode
Band
3GPP Requirement
Tx Power(dBm)
Note
WCDMA
Band I
24+1.7/-3.7
23.5±1
Band V
24+1.7/-3.7
23.5±1
Band VIII
24+1.7/-3.7
23.5±1
LTE FDD
Band 1
23±2.7
23±1
10MHz Bandwidth, 1 RB
Band 3
23±2.7
23±1
10MHz Bandwidth, 1 RB
Band 5
23±2.7
23±1
10MHz Bandwidth, 1 RB
Band 7
23±2.7
23±1
10MHz Bandwidth, 1 RB
Band 8
23±2.7
23±1
10MHz Bandwidth, 1 RB
Band 20
23±2.7
23±1
10MHz Bandwidth, 1 RB
Band 28
23+2.7/-3.2
23±1
10MHz Bandwidth, 1 RB

Fibocom L830-EB Specifications

General

Category	Computer Hardware
Manufacturer	Fibocom
Model	L830-EB
Form Factor	M.2
Operating Temperature	-10°C to +55°C
LTE Bands	B1/B3/B5/B7/B8/B20
3G Bands	B1/B5/B8
Data Rate	LTE Cat4: 150Mbps DL / 50Mbps UL
Interface	PCIe, USB 2.0
Operating Voltage	3.135V to 4.4V
