Pin Pin Name I/O Reset Value Pin Description Type
69 CONFIG_1 O
L
Internally connected to GND
75 CONFIG_2 O
L
Internally connected to GND
The M.2 module configuration as the following table:
Config_0
(pin21)
Config_1
(pin69)
Config_2
(pin75)
Config_3
(pin1)
Module Type and Main
Host Interface
Port
Configuration
GND GND GND NC
WWAN–USB3.1, PCIe
Gen1
0
Please refer to PCI Express M.2 Specification Rev1.1” for more details.
3.11 Other Interfaces
The module does not support other interfaces yet.
