L850-GL Hardware User Manual Page 47 of 54
Mode Band 3GPP Requirement (dBm)
Rx Sensitivity(dBm)
Typical
Note
Band 20 -93.3 -102.5 10MHz Bandwidth
Band 21 -96.3 -99 10MHz Bandwidth
Band 26 -93.8 -103 10MHz Bandwidth
Band 28 -94.8 -103 10MHz Bandwidth
Band 29 -93.3 -101 10MHz Bandwidth
Band 30 -95.3 -99.5 10MHz Bandwidth
Band 66 -95.8 -101.5 10MHz Bandwidth
LTE TDD
Band 38 -96.3 -101 10MHz Bandwidth
Band 39 -96.3 -101.5 10MHz Bandwidth
Band 40 -96.3 -100.5 10MHz Bandwidth
Band 41 -94.3 -100 10MHz Bandwidth
Note:
The above values are measured for the dual antennas situation (Main+Diversity). For single
main antenna (without Diversity), the sensitivity will drop around 3dBm for each band of LTE.
4.5 GNSS
L850 module supports GNSS/BeiDou and AGNSS functions, and adopts RF Diversity and GNSS/Beidou
integrated antenna.
Description Condition Test Result
Power
GPS fixing 120mA / -130dbm
GPS tracking 120mA / -130dbm
GLONASS fixing 120mA / -130dbm
GLONASS tracking 125mA / -130dbm
BeiDou fixing 120mA / -130dbm
BeiDou tracking 120mA / -130dbm
GPS Sleep 0.7mA
GLONASS Sleep 0.8mA
BeiDou Sleep 0.7mA
TTFF GPS Cold start 37s / -130dBm
