1. Set F26 (near zero value) according to application requirement or 00000 to disable near zero value
control. Refer to 13.1 for more information about F26 near zero function.
2. Refer to 5.5.4 on comport settings and set Check Control = On.
3. In ATM mode, refer to 12.1 to enter LO and HI limit.
9.3.1.2 Settings of weight Check Control for ATM when no external peripheral is connected to
instrument.
1. Set both Comport 1 and Comport 2 to Off on F16 and F17.
2. Set F26 (near zero value) according to application requirement or 00000 to disable near zero value
control. Refer to 13.1 for more information about F26 near zero function.
3. At this point, ATM comport setup is completed for this mode.
10. Peak Hold Mode
10.1 Description of Peak Hold Mode
Under this mode, the instrument will display and hold the highest load/force detected. This mode can be used
for tension (positive) or compression (negative) tests, all peak results are treated as absolute values.
10.2 Comport Settings for Peak Hold Mode
Refer to 5.5 on comport settings. Output type parameters Auto 1 ~ 3 are not suggested. If a printer is used, set
the connected comport to Manual and the other comport to any data string related modes.
During comport setting procedures, following the below recommendation for parameters selection.
a. Baud rate setting. If an external peripheral is used, always use the highest available baud rate of it.
The highest baud rate this instrument can support is 256000. Baud rate of the peripheral has to be
set accordingly.
b. Parity setting: -
• Set according to the external peripheral connected.
• Select any if there is no external peripheral is connected.
c. Data length setting: -
• Set according to the external peripheral connected.
• Select any if there is no external peripheral is connected.
d. Auto Accumulation setting: - Select any. Instrument will deem No as default value for this mode.
e. Check Control setting: - Select Off.
f. Stability control setting: - Select any. Instrument will deem No as default value for this mode.
g. Minimum output setting: - Select any. Instrument will deem 0d as default value for this mode.
h. Print format setting: - Set according to the external peripheral connected.
At this point, comport setup is completed for this mode.
10.3 Start Using Peak Hold
a. Refer to 6.6 on how to select the desired weight unit.
b. Refer to 6.5 on how to enter Peak Hold mode.
c. Complete all necessary test setup. If mounting/support accessories are used, apply all of them.
d. Press [Tare] to cancel the effect of any extra loads.
