15. Printing Formats
15.1 Lab 1 Print Format
47
No header will be generated when line number is set = 00. See below tables for print format illustrations and
explanations.
15.1 Weighing, ATM & Animal Mode Illustration
Date
Time
Seq
Net
Tare
Gross
Total
Ref.
R
4/23/202
0
14:14:55
1 W
5.000kg
0.000kg
5.000kg
5.000kg
L
4/23/202
0
14:14:58
2 W
9.999kg
0.000kg
9.999kg
14.999k
g
L
4/23/202
0
14:15:00
3 W
14.993k
g
0.000kg
14.993k
g
29.992k
g
A
4/23/202
0
14:15:03
4 W
19.997k
g
0.000kg
19.997k
g
49.989k
g
H
15.2 Piece Count Mode Illustration
Date
Time
Seq
Net
Tare
Gross
Total
Ref.
R
4/23/202
0
14:17:0
1
1 C
100 P
0.000kg
5.002kg
5.002kg
50.005g
L
4/23/202
0
14:17:0
4
2 C
200 P
0.000kg
10.000k
g
15.002k
g
50.005g
L
4/23/202
0
14:17:0
6
3 C
300 P
0.000kg
14.994k
g
29.996k
g
50.005g
L
4/23/202
0
14:17:0
9
4 C
400 P
0.000kg
19.998k
g
49.994k
g
50.005g
L
Explanations: -
• Date = Date of Output
• Time = Time of Output
Seq = Accumulate Sequence No & Working
Mode Type
o W = Weighing, C = Piece count
• Net = Net Weight
• Tare = Tare Weight
• Gross = Gross Weight
• Total = Total Accumulated Weight
• Ref. = Unit weight
• Result = Check Result: -
o A = Within Lo & Hi limit
o L = Lower than Lo limit
o H = Higher than Hi Limit
47
Lab 1 format does not support Customer or Produce Code.
