15.2.3 Standard Lab 2 print format for Peak Hold mode
Refer to below diagram for printout content.
15.2.4 Standard Lab 2 print format for Animal Weighing mode
Refer to below diagram for printout content.
Time
21:43:12
Time of Output
Date
2020-03-28
Date of Output
Seq
1
Accumulate Sequence No.
Name
Customer Code
Customer Code (if entered)
Pcode
Product Code
Product Code (if entered)
Hold.W
2.998kg
Weight Held
Total
2.998kg
Total Accumulated Weight
15.3 Customizing Lab 2 Print Format
49
Custom printout is available for the below modes: -
• Weighing.
• Auto-Tare-Memory.
• Piece Count.
• Animal weighing.
19 variants + 2 commands (Cr LF and End) are available for custom print output format. Refer to the below Print output
format variants table for more detail.
49
When Lab 2 is selected under in F16 and/or F17
