51
Custom PC Output Content Table
Symbol
Explanations
Nature
No. of
Digit
Remarks
CoMMA
Comma
Data Separator
1
SemiCo
Semi Colon
1
Cr LF
HEX Code 0D 0A
Control Code
2
Cr
HEX code 0D
1
LF
HEX code 0A
1
SOH
HEX code 01
1
STX
Hex code 02
1
ETX
Hex code 03
1
Status
Weigh Status
Transaction Data
2
ST = Stable / US = Unstable / OL
= Overload
nT-GS
Net/Gross Sign
2
NT = Net / GS = Gross
Date
Date of Output
10
Time
Time of Output
8
Net
Net Weight
8
Tare
Tare Weight
8
Gross
Gross Weight
8
Unit
Weight Unit
2
kg = Kilogram / (space)g =g / lb =
Pound
H ref
Hi Limit
8
8-digital including decimal (if any)
L ref
Lo Limit
8
8-digital including decimal (if any)
Ck res
Comparison Result
2
LO/OK/HI / Grade Result for
grading
id
Machine ID
2
01 ~ 99, ** = None
Group
Machine Group Number
2
00 ~ 99, ** = None
Op Code
Operator Number
4
0000 ~ 9999, **** = None
P Code
Product Code
1 ~ 18
Blank = not entered
C Code
Customer Code
1~ 18
Blank = not entered
Trans
No. of accumulated
transaction
8
Blank = none
ACC
Total Accumulated
Weight
Transaction Data
8
Blank = none
unit.Wt
Average piece weight
8
When weight unit is = kg, unit
weight is based on g
Count
Number of piece
8
Piece Counting Mode only
t.Count
Total Accumualted
Pieces
8
Piece Counting Mode only
Ani
Weight hold (Animal
Weighing)
8
Animal Weighing Mode Only
PEAk
Peak Value
8
Peak Hold Mode Only
End
End of Input
None
