55
stability control,
transmission interval,
Auto Accumulation,
number of copy,
check result control,
print format, label
format group 1 file
number, label format
group 2 file number,
data length, parity,
minimum output
weight value
 d2 = baud rate: - 0 = 1200; 1 = 2400; 2 = 4800; 3 = 9600; 4 =
19200; 5 = 38400; 6 = 57600; 7 = 115200; 8 = 256000
 d3 = protocol: - 0 = Protocol 1; 1 = Protocol 2; …; 8 = Protocol 9
 d4 = print stability control: - 0 = no (disable); 1 = Yes (enable)
 d5 = transmission interval: - 0 = int 0; 1 = int 0.5; 2 = int 1.0; 3 =
int 1.5; ….; 9 = int 300.
 d6 = Auto Accumulation: - 0 = Off (disable); 1 = On (enable)
 d7 = number of copy: - 0 = 1 copy; … 7 = 8 Copy
 d8 = check result control: - 0 = no (disable); 1 = Yes (enable)
 d9 = print format: - 0 = Lab 1; 1 = Lab 2; 2 = Lab 3; 3= Lab 4; 4
= Lab 5; 5 = LP-50; 6 = TSC; 7 = Sbarco
 d10 =label format group 1 file number (00~99): - 00 = file AA00;
1 = file AA01; …98 = file AA98; 99 = file AA99
 d11 = label format group 2 file number (00~99): - 00 = file
BB00; 1 = file BB01; …98 = file BB98; 99 = file BB99
 d12 = data length: - 0 = 7bit; 1 = 8bit
 d13 = parity: = 0 = none; 1 = 0dd; 2 = even
 d14 = minimum output weight value: - 0 = from 00d; 01 = from
01d; …; 20 = from 20d. Data length = 2 with leading zero
As
Comport 2 working
mode, baud rate,
output protocol, print
stability control,
transmission interval,
Auto Accumulation,
number of copy,
check result control,
print format, label
format group 1 file
number, label format
group 2 file number,
data length, parity,
minimum output
weight value
 d1 = working mode: - 0 = Auto 1; 1 = Auto 2; 2 = Auto 3; 3 =
Manual; 4 = PC; 5 = CMD; 6 = Off
 d2 = baud rate: - 0 = 1200; 1 = 2400; 2 = 4800; 3 = 9600; 4 =
19200; 5 = 38400; 6 = 57600; 7 = 115200; 8 = 256000
 d3 = protocol: - 0 = Protocol 1; 1 = Protocol 2; …; 8 = Protocol 9
 d4 = print stability control: - 0 = no (disable); 1 = Yes (enable)
 d5 = transmission interval: - 0 = int 0; 1 = int 0.5; 2 = int 1.0; 3 =
int 1.5; ….; 9 = int 300.
 d6 = Auto Accumulation: - 0 = Off (disable); 1 = On (enable)
 d7 = number of copy: - 0 = 1 copy; … 7 = 8 Copy
 d8 = check result control: - 0 = no (disable); 1 = Yes (enable)
 d9 = print format: - 0 = Lab 1; 1 = Lab 2; 2 = Lab 3; 3= Lab 4; 4
= Lab 5; 5 = LP-50; 6 = TSC; 7 = Sbarco
 d10 =label format group 1 file number (00~99): - 00 = file AA00;
1 = file AA01; …98 = file AA98; 99 = file AA99
 d11 = label format group 2 file number (00~99): - 00 = file
BB00; 1 = file BB01; …98 = file BB98; 99 = file BB99
 d12 = data length: - 0 = 7bit; 1 = 8bit
 d13 = parity: = 0 = none; 1 = 0dd; 2 = even
 d14 = minimum output weight value: - 0 = from 00d; 01 = from
01d; …; 20 = from 20d. Data length = 2 with leading zero
At
Current weight unit
and function mode
 d1 = weight unit: - 0 = kg; 1 = g; 2 = lb
 d2 = function mode: - 0 = weighing; 1 = piece count; 2 = AT 1; 3
= peak hold; 4= animal weighing
Av
Auxiliary Function
mode enable/disable
status
 d1 = Piece count: - 0 = Off; 1 = On
 d2 = ATM: - 0 = Off; 1 = On
 d3 = Peak Hold: - 0 = Off; 1 = On
 d4 = Animal Weighing: - 0 = Off; 1 = On
Aw
Machine ID & group
number
 d1 = 4-digit machine ID number. Nothing = no machine ID is set
 d2 = 2-digit machine group number. Nothing = no group number
is set
Ax
Operator Number
4-digit operator number. **** = no operator number is set
