Fimap BMg Series - Operating Mode

5.5 Operating mode
WASHING
Operator Seat
Microsw.
Action Result
Sitting Closed Washing Enabled
Forward pedal pressed
Brushdeck Actuator goes down (+24V to M4)
Brush Motors ON after 1,5 seconds (+24V to
M2a-M2)
Solution Pump ON if water level is different than
0 (+24V to Pa)
Solenoid Valve ON if water level is different than
0 (+24V to J11-13 to J11-5)
Sitting Closed Dosing system enabled
during work
Chemical Pump ON if water level is different than
0 (+24V to Pd)
Sitting Closed Backward function enabled
during work
Brushdeck Actuator goes down (+24V to M4)
Brush Motors ON (+24V to M2a-M2)
Solution Pump OFF
Solenoid Valve OFF
Chemical Pump OFF (if available)
Sitting Closed Traction Pedal not pressed
during work
Brushdeck Actuator rises after 10 seconds (-24V
to M4)
Brush Motors OFF
Solution Pump OFF
Solenoid Valve OFF
Chemical Pump OFF (if available)
Sitting Closed Washing disabled
during work
Brushdeck Actuator rises (-24V to M4)
Brush Motors OFF
Solution Pump OFF
Solenoid Valve OFF
Chemical Pump OFF (if available)
