Fimap BMg Series - Technical Data

1.7 Technical Data
BMG Technical Data
TECHNICAL DESCRIPTION U/M 56 65 50 BTO
Working capacity, up to
m
2
h
/
ft
2
h
5400/58125 5400/58125 5400/58125
Total Power W 3050 3250 3250
Disc Brushes (Number - Ø External) Nr - mm/in 2-460/18.1 2-460/18.1 -
Pad (Number - Length - Width) Nr - mm-mm - - 1-508-355
Nr - in-in - - 1-20-14
Brush Motor
(Voltage - Nominal Power - Revolutions)
V-W-rpm 36-750-180 36-750-180 36-750-180
Max weight on Brush Kg/lb 150/331 150/331 150/331
Traction Motor (Voltage - Nominal Power) V-W 24-450 24-450 24-450
Maximum Ramp Gradient (Transfer)
1
% 18 18 18
Maximum forward speed (Transport) (Default) Km/h / mph 9/5.6 9/5.6 9/5.6
Vacuum Motor (Voltage - Nominal Power) V-W 36-650 36-650 36-650
Vacuum Motor Stages/Depression mbar 2/190 2/190 2/190
Solution Tank L/gal 190/50 190/50 190/50
Recovery Tank L/gal 200/53 200/53 200/53
Detergent Tank L/gal 15/4 15/4 15/4
Steering Ray mm/in 986/38.8 986/38.8 986/38.8
Battery compartment (length - width - height) mm 190(2x)-350-310
in 7.5(2x)-13.7-12.2
Usage Temperature (Min - Max) ° C 0 - 40 0 - 40 0 - 40
° f 32-104 32-104 32-104
Sound pressure level (ISO 11201) LpA dB (A) ≤ 70 ≤ 70 ≤ 70
Hand vibration level (ISO 5349)
m
s
2
≤ 1,10 ≤ 1,10 ≤ 1,10
1
”Transfer” setting and empty Tanks
8
