Fimap BMg Series - Work Requirements; Operating Mode

8.3 Work requirements
The traction unit only works if the following conditions are met:
1. The batteries are not discharged.
2. The operator is seated on the machine so as to press the
seat safety switch (1).
3. The machine is on (2).
4. The electrobrake is activated.
5. The accelerator pedal is pressed(4).
8.4 Operating mode
TRACTION
Operator Seat
Microsw.
Action Result
Sitting Closed Forward pedal pressed Traction motor ON +24V to M1).
Sitting Closed Backward function enabled Traction motor ON (-24V to M1).
89
