2.4 Frame and traction system: what to do if. . .
The traction motor doesn’t work properly
1. The machine is switched off ⇒ Switch on the machine.
2. The machine doesn’t switch on ⇒ Check the proper section (see section 2.1 at page 17).
3. The display shows an alarm message ⇒ Check what alarm message is shown and solve
the related issue by following the proper instruc-
tions (see section 3.4.1 at page 34).
4. The operator is not sitting on the seat ⇒ The operator must sit on the seat.
5. The operator is sitting on the seat ⇒ Check and/or replace the seat (see section 3.3 at
page 27).
6. The pedal is not pressed ⇒ Press the pedal depending on the required speed.
7. The pedal is pressed ⇒ Check and / or replace the traction pedal (see
section 3.3 at page 27).
8. The traction motor is not supplied ⇒ Check the power connections of the motor (see
section 8.5 at page 90).
9. The traction motor carbon brushes are worn out ⇒ Replace the carbon brushes (see section 8.7.3 at page
93).
10. The traction motor is not working even if pow-
ered
⇒ Replace the motor (see section 3.3 at page 27).
11. The electrobrake doesn’t disengage ⇒ Check the connections of the electrobrake.
