7.5 Operating mode
VACUUM
Operator Seat
Microsw.
Action Result
Sitting Closed Vacuum Enabled
Forward pedal pressed
Squeegee Actuator goes down (+24V to M5)
Vacuum motor ON (+24V to M3)
Sitting Closed Backward function enabled
during work
Squeegee Actuator rises (-24V to M5).
Sitting Closed Traction Pedal not pressed
during work
Vacuum motor OFF after 10 seconds at maxi-
mum level.
Sitting Closed Vacuum Disabled
during work
Squeegee Actuator rises (-24V to M5)
Vacuum Motor OFF after 10 seconds at maxi-
mum level.
VACUUM WAND
Operator Seat
Microsw.
Action Result
Standing Open Wand button enabled Vacuum motor ON (+34V to M3)
Squeegee Actuator goes down (+24V to M5)
Standing Open Wand button disabled Vacuum motor OFF (+0V to M4) after 10 sec-
onds at maximum level.
Squeegee Actuator rises (-24V to M5) after the
next traction consent.
