Loosen the locknut (C) and unscrew the knob completely (D).
Remove the rear support.
Unscrew the nut and release the pressure spring (E).
Remove the seeger to remove the pin and remove the front
support.
7.8.2 Squeegee Actuator
Lower the squeegee and turn off the machine.
Remove the batteries and the battery tray.
Disconnect the connector (A).
Remove the seegers to remove the pins (B, C) and remove the
actuator.
