RECYCLE SYSTEM
Operator Seat
Microsw.
Action Result
Sitting Closed Recycled button enabled
Solution tank reserve floater
enabled
Recovery tank reserve floater
disabled
Forward pedal pressed
Recycle Pump ON (+24v ref to j7-2/j7-4).
Sitting Closed Recovery tank reserve floater
enabled
Recycle Pump OFF (+0V ref to J7-1/J7-3).
Sitting Closed Recycled button disabled Recycle Pump OFF (+0V ref to J7-1/J7-3).
97
