EN
113
Check sequence: Negative to ground (PE)
1D (-) PE
2A (-) PE
2B (-) PE
2C (-) PE
2D (-) PE
3A (-) PE
3B (-) PE
3C (-) PE
3D (-) PE
4A (-) PE
4B (-) PE
4C (-) PE
4D (-) PE
5A (-) PE
5B (-) PE
5C (-) PE
5D (-) PE
6A (-) PE
6B (-) PE
6C (-) PE
6D (-) PE
Check sequence: Positive to negative
First point Second point
1A (+) 1A (-)
1B (+) 1B (-)
1C (+) 1C (-)
1D (+) 1D (-)
2A (+) 2A (-)
2B (+) 2B (-)
2C (+) 2C (-)
2D (+) 2D (-)
3A (+) 3A (-)
3B (+) 3B (-)
3C (+) 3C (-)
3D (+) 3D (-)
4A (+) 4A (-)
4B (+) 4B (-)
4C (+) 4C (-)
4D (+) 4D (-)
5A (+) 5A (-)
5B (+) 5B (-)
5C (+) 5C (-)
5D (+) 5D (-)
6A (+) 6A (-)
6B (+) 6B (-)
6C (+) 6C (-)
6D (+) 6D (-)
8.2.4.11 Voltage absence test on AC side (wiring box)
Visually inspect the components to identify the presence of any overheating, signs of electric arcs, failure of the insulating devices, loosen
connections or cables not connected.
Using a Philip screwdriver, unscrew the blocking screw (B) on the AC protective shield (27).
Open the sliding cover (A) as shown in the picture and block it in open position using the blocking screw (B). The opening of the sliding
cover will open the 6 holes that make accessible the VAT points on the AC connection busbar (21).
