Audio Command Center Series Manual — P/N 51889:E1 6/8/2010 35
Field Programming
5 4 OFF and 5 OFF = No AC Loss Delay
4 OFF and 5 ON = 6 Hour Delay
4 ON and 5 OFF = 2 Hour Delay
4 ON and 5 ON = not used (Invalid Setting)
6 Enable All-Call during Remote Mic. Page
8
Disable All-Call during Remote Mic. Page
8
- factory default
7 Enable ACC-25/50ZST operation Enable ACC-25/50 orACC-25/50ZS operation
8 Only AC Loss Relay will transfer upon an AC
loss condition.
The CMD1 & Form-C Trouble Relays will track the AC Loss
Relay and transfer upon an AC loss condition.
1 Dual Zone operation directs a single message to either or both amplifier circuits (factory default setting).
2 Dual Zone is not permitted for ACC-25/50ZS or ACC-25/50ZST.
3 CMD1 has the highest priority, CMD5 has the lowest priority.
4 AAM1 refers to the first ACC-AAM25 amplifier circuit and AAM2 refers to the second ACC-AAM25
amplifier circuit.
5 Single Zone operation directs the same message to both amplifier circuits.
6 CMD inputs are not used for activation when ACC-ZPMK is installed with the MS-9200UD, MS-9200UDLS
and MS-9600 Version 2.0 or later. 4.7 K End-of-Line resistors must still be connected across CMD3,
CMD4 and CMD5.
7 When using Distributed Audio Panels, the ACC-25/50 must be configured as single zone.
8 This option defaults to ON for the ACC-25/50ZS and ACC-25/50ZST system.
S3 DIP Switch ON OFF
Table 2.3 S3 DIP Switch Settings on ACC-25/50 Series Motherboard (ACC-MCB)
S1 DIP Switch ON OFF
1 This switch works in conjunction with switches 2 & 3 to configure for operation with specific FACP
2 This switch works in conjunction with switches 1 & 3 to configure for operation with specific FACP
3 1 OFF, 2 OFF, 3 OFF = No FACP, MS-9200UD version 1 or non-ACS FACP connected to ACC-25/50ZS/T-
(factory default setting)
1 OFF, 2 OFF, 3 ON = MS-5210UD connected to ACC-25/50ZS/T
1 OFF, 2 ON, 3 OFF = MS-9200 connected to ACC-25/50ZS/T
1 OFF, 2 ON, 3 ON = MS-9600 version 1 connected to ACC-25/50ZS/T
1 ON, 2 OFF, 3 OFF = MS-9600 version 2 or higher connected to ACC-25/50ZS/T
1 ON, 2 OFF, 3 ON = MS-9200UDLS and MS-9200UD version 2 or 3 connected to ACC-25/50ZS/T
1 ON, 2 ON, 3 OFF = ANN-BUS Protocol, MS-9600LS, or MS-9200UDLS version 4 or higher, MS-5UD-3, MS-5UD-
7, MS-10UD-3, and MS-10UD-7 version 2 or higher connected to ACC-25/50ZS/T
1 ON, 2 ON, 3 ON = future use
4 not used (future)
5 not used (must be set to OFF)
6 This switch works in conjunction with switches 7 & 8 to set the number of ACC-25/50DAZS panels connected
7 This switch works in conjunction with switches 6 & 8 to set the number of ACC-25/50DAZS panels connected
8 6 OFF, 7 OFF, 8 OFF = No ACC-25/50DAZS Distributed Audio Panels connected to ACC-25/50ZS/T
6 OFF, 7 OFF, 8 ON = 1 ACC-25/50DAZS Distributed Audio Panel connected to ACC-25/50ZS/T
6 OFF, 7 ON, 8 OFF = 2 ACC-25/50DAZS Distributed Audio Panels connected to ACC-25/50ZS/T
6 OFF, 7 ON, 8 ON = 3 ACC-25/50DAZS Distributed Audio Panels connected to ACC-25/50ZS/T
6 ON, 7 OFF, 8 OFF = 4 ACC-25/50DAZS Distributed Audio Panels connected to ACC-25/50ZS/T
6 ON, 7 OFF, 8 ON = 5 ACC-25/50DAZS Distributed Audio Panels connected to ACC-25/50ZS/T
Table 2.4 S1 DIP Switch Settings on ACC-ZPMK (ACC-25/50ZS & ACC-25/50ZST)
