27
LOCKOUT HISTORY
The sub-menu “LOCKOUT HISTORY” will display the last six (6) lockouts, along with the burner
cycle and burner hour when the lockout occurred. When the MODE key is pressed, the screen will
display the most recent lockout condition and the number of that lockout (e.g. LO #127 represents
the 127th lockout of that control). The SCRL key will display the Burner Hour, followed by the
Burner Cycle when the lockout occurred. The SCRL key will advance to the next lockout, and repeat
the sequence listed above. The MODE key will exit the sub-menu.
PROGRAM SETUP
The sub-menu “PROGRAM SETUP” allows the user to review the various operational settings of
the programmer module (e.g. programmer type, purge timing, etc.). The MODE key is used to enter
the “PROGRAM SETUP” sub-menu, and the SCRL key is used to advance through the sub-menu.
MODE AUTO 45 Programmer Type is an MEP230.
PROGRAMR MEP230
SCRL AUTO 45 Software Engineering code of the programmer module is code 5.
ENGR CODE NO. 5
SCRL AUTO 45 Amplifier module is an EUV1 or an ERT1.
AMP. TYPE= MEUV
SCRL AUTO 45 Flame Failure Response Time (FFRT) is 3 seconds.
FLAME FAIL TIME = 3s
SCRL AUTO 45 Purge timing (selected by the dipswitches) is 7 seconds.
PURGE TIME = 7s
SCRL AUTO 45 Prove 7-6 open to start is disabled (selected by dipswitches).
PROVE 7-6 OPEN = N
SCRL AUTO 45 Post purge time is 0 seconds (selected by dipswitches).
POST PURGE = 0s
SCRL AUTO 45 Control recycles on flame fail (selected by dipswitches).
TYPE RECYCLE
SCRL AUTO Unit Address is 00. Refer to section on communications.
PRESS SCREEN DISPLAYS DESCRIPTION
SCRL AUTO 45
LOCKOUT HISTORY
Scrolling through the historical information.
MODE LO #127 PTFI
FLAME FAIL
The latest (most recent) lockout condition. This is the 127th lockout of
the control. History indicates the lockout occurred during PTFI.
SCRL LO #127 PTFI
@ BNR HOURS 136
The last lockout occurred after 136 hours of burner operation.
SCRL LO #127 PTFI
@ BNR CYCLE 744
The last lockout occurred at burner cycle 744.
SCRL LO #126 PURGE
AIR FLOW OPEN
The second latest lockout condition. This is the 126th lockout of the con-
trol. History indicates the lockout occurred during purge.
MODE AUTO 45
FLAME SIGNAL
Screen has returned to the normal run message.
