55
M-SERIES TO M-SERIES II TO MICROM CROSS REFERENCE LISTING
M-SERIES M-SERIES II REPLACEMENT MODULES MicroM REPLACEMENT MODULES
Part
Number
Chassis Amplifier Programme
r
Programmer
Dipswitch #8
Chassis Amplifier Programmer Programmer
Dipswitch #6
UVM1D MC120 MAUV1T MP100 N/A MEC120 MEUV1 MEP100 N/A
UVM1F MC120 MAUV1 MP100 N/A MEC120 MEUV4 MEP100 N/A
TFM1D MC120 MART1T MP100 See Note #1 MEC120 MERT1 MEP100 N/A
TFM1F MC120 MART1 MP100 See Note #1 MEC120 MERT4 MEP100 N/A
UVM2 MC120 MAUV1 MP230 OFF MEC120 MEUV4 MEP230 C
TFM2 MC120 MART1 MP230 OFF MEC120 MERT4 MEP230 C
UVM3 MC120 MAUV1 MP230 ON MEC120 MEUV4 MEP230 O
TFM3 MC120 MART1 MP230 ON MEC120 MERT4 MEP230 O
UVM3H MC120 MAUV1 MP230H ON MEC120 MEUV4 MEP230H O
TFM3H MC120 MART1 MP230H ON MEC120 MERT4 MEP230H O
UVM5 MC120 MAUV1 MP560 ON MEC120 MEUV4 MEP560 O
UVM6 MC120 MAUV1 MP560 See Note #2 MEC120 MEUV4 MEP560 C
- N/A — Not Applicable
- Programmer Dipswitches apply to MP230H, and MP560 only.
- Dipswitch #8 sets Recycle / Non-Recycle Operation.
- MP560 Programmer Module has “Check-Run” Switch.
- Note #1: For Standing Pilot, clip out red jumper on MP100. See fig 19
on page 55.
- Note #2: Dipswitch #8 ON when red jumper of UVM6 is clipped.
- N/A — Not Applicable
- Programmer Dipswitches apply to MEP200, and MEP500
Series Programmers
- Dipswitch #6 sets Recycle / Non-Recycle Operation.
(O = Non-Recycle, C = Recycle)
- MEP500 Series Programmer Module has “Check-Run”
Switch.
PURGE PTFI M-Series II PROGRAMMER DIPSWITCH SETTINGS MicroM PROGRAMMER DIPSWITCH
SETTINGS
TIME TIME #1 #2 #3 #4 #5 #6 #7 #1 #2 #4
7 5 ON OFF OFF OFF OFF ON OFF C C C
7 5 OFF ON OFF OFF OFF ON OFF C C C
30 5 OFF OFF ON OFF OFF ON OFF O C C
7 10 OFF ON OFF OFF OFF OFF ON C C 0
90 5 OFF OFF ON ON OFF ON OFF O O C
30 10 OFF OFF ON OFF OFF OFF ON O C O
60 10 OFF OFF OFF ON OFF OFF ON C O 0
90 10 OFF OFF ON ON OFF OFF ON O O 0
- Dipswitches #1 through #5 set Purge Timing
- Dipswitches #6 and #7 set TFI Timing
- Dipswitches #1 through #2 set
Purge Timing
- Dipswitch #4 sets TFI Timing
M-SERIES TIMING CARDS PURGE TIME PTFI TIME
MT55
5 5
MT74
7 4
MT304
30 4
MT710
7 10
MT904
90 4
MT3010
30 10
MT6010
60 10
MT9010
90 10
